Firewall General |
|---|
| Operating system | SonicOS 7.0.1 |
| Interfaces | 2x40G; 8x25G, 4 x10G/5G/2.5/1G SFP+, 4 x 10G/5G/2.5G/1G (Cu), 16 x 1GbE (Cu), 2 USB 3.0, 1 Console, 1 Mgmt. port |
| Expansion | Storage Expansion Slot (Up to 1TB) |
| Storage | 256GB M.2 |
| VLAN Interfaces | 512 |
| Access points supported (maximum) | 512 |
Firewall/VPN Performance |
|---|
| Firewall inspection throughput | 36 Gbps |
| Threat Prevention throughput | 19 Gbps |
| Application inspection throughput | 20 Gbps |
| IPS throughput | 20 Gbps |
| Anti-malware inspection throughput | 18.5 Gbps |
| TLS/SSL decryption and inspection throughput (DPI SSL) | 9 Gbps |
| IPSec VPN throughput | 19 Gbps |
| Connections per second | 228 000 |
| Maximum Connections (SPI) | 8 000 000 |
| Maximum DPI-SSL Connections | 750 000 |
| Maximum connections (DPI) | 6 000 000 |
VPN |
|---|
| Site-to-site tunnels | 6000 |
| SSL VPN licenses (max) | 2 (1500) |
| IPSec VPN clients (max) | 2000 (6000) |
| Encryption/Authentication | DES, 3DES, AES (128, 192, 256-bit)/MD5, SHA-1, Suite B Cryptography |
| Key exchange | Diffie Hellman Groups 1, 2, 5, 14v |
| Route-based VPN | RIP, OSPF, BGP |
| Certificate support | Verisign, Thawte, Cybertrust, RSA Keon, Entrust and Microsoft CA for SonicWall-to- SonicWall VPN, SCEP |
| VPN features | Dead Peer Detection, DHCP Over VPN, IPSec NAT Traversal, Redundant VPN Gateway, Route-based VPN |
| Global VPN client platforms supported | Microsoft® Windows Vista 32/64-bit, Windows 7 32/64-bit, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit, Windows 10 |
| NetExtender | Microsoft Windows Vista 32/64-bit, Windows 7, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit, Mac OS X 10.4+, Linux FC3+/Ubuntu 7+/OpenSUSE |
| Mobile Connect | Apple® iOS, Mac OS X, Google® Android™, Kindle Fire, Chrome, Windows 8.1 (Embedded) |
Security Services |
|---|
| Deep Packet Inspection services | Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, DPI SSL |
| Content Filtering Service (CFS) | HTTP URL, HTTPS IP, keyword and content scanning, Comprehensive filtering based on file types such as ActiveX, Java, Cookies for privacy, allow/forbid lists |
| Comprehensive Anti-Spam Service | Supported |
| Application Visualization | Yes |
| Application Control | Yes |
| Capture Advanced Threat Protection | Yes |
Networking |
|---|
| IP address assignment | Static, (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP relay |
| NAT modes | 1:1, 1:many, many:1, many:many, flexible NAT (overlapping IPs), PAT, transparent mode |
| Routing protocols | BGP, OSPF, RIPv1/v2, static routes, policy-based routing |
| QoS | Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1p |
| Authentication | LDAP (multiple domains), XAUTH/RADIUS, SSO, Novell, internal user database, Terminal Services, Citrix, Common Access Card (CAC) |
| Local user database | 3200 |
| VoIP | Full H323-v1-5, SIP |
| Standards | TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3 |
| Certifications pending | FIPS 140-2 (with Suite B) Level 2, UC APL, VPNC, IPv6 (Phase 2), ICSA Network Firewall, ICSA Anti-virus, Common Criteria NDPP (Firewall and IPS) |
| High availability | Active/Active with stateful synchronization |
Hardware |
|---|
| Form factor | 1U Rack Mountable |
| Power supply (W) | 1x350W |
| Maximum power consumption (W) | 139.2 |
| Input power | 100-240 VAC, 50-60 Hz |
| Total heat dissipation | 474.7 BTU |
| Dimensions | 43 x 46.5 x 4.5 (cm) 16.9 x 18.1 x 1.8 in |
| Weight | 8.1 kg |
| WEEE weight | 9.9 kg |
| Shipping weight | 13.8 kg |
| Major regulatory | FCC Class A, CE (EMC, LVD, RoHS), C-Tick, VCCI Class A, MSIP/KCC Class A, UL, cUL, TUV/GS, CB, Mexico CoC by UL, WEEE , REACH, ANATEL, BSMI |
| Environment (Operating/Storage) | 32°-105° F (0°-40° C)/-40° to 158° F (-40° to 70° C) |
| Humidity | 0-90% non-condensing |
